WASH 300

Category: LED Moving Head Series Tag: Model No :11002001

Equipped with a cutting-edge lamp source that boasts an impressive average life of 50,000 hours
Its beam angle can be adjusted from 8° to 54°, allowing for versatile lighting effects.
Featuring 19 powerful 15W RGBW 4in1 LEDs and a high-quality optical lens, this lighting fixture ensures impeccable performance.
Delivers a mesmerizing display of RGBW 4-in-1 colors
Captivating color macro and gradual color change effects.

Description

Powerful LED Performance

The moving head light is a powerful and high-performance LED beam wash moving head that is perfect for a wide range of applications. With its extreme brightness and zoom range that can be adjusted from 8° to 54°, this fixture delivers exceptional performance whether used as a beam light with multi-color rays or as a wash light with a wide projection.

Versatile Lighting

Designed for use in medium to large venues, this moving head light is the perfect solution for TV studios and other applications where top-of-the-line visual effects or perfectly uniform wash lighting are required. The fixture is equipped with 19pcs of 15W RGBW 4in1 LEDs, which deliver a wide range of colors and effects, making it a versatile choice for any lighting setup.

High Versatility for Moving Head Light

The WASH 300 is a high-performance and versatile LED beam wash moving head that is ideal for a wide range of applications. Its exceptional brightness and zoom range, along with its 19 RGBW 4in1 LEDs, make it an excellent choice for anyone looking for powerful and flexible lighting solutions.

Additional information

Lamp Source	Average Life: 50000 hours, Beam angle: 8°- 54°, Lamp type: 19pc 15W RGBW 4in1 LED, Lens: High quality optical lens
Color System	RGBW 4 in 1
Effects	All-optical domain dimming High light output, low glare Fast Strobe: 1-25HZ Color macro and gradual color change eﬀects
Moving Parameter	Angle: Pan 540° Tilt 270° PAN and TILT adopt an electro-optic reset system which automatically resets the parameters if any change is caused by accident.
Power Supply	AC100-240V 50/60Hz Switch Power Consumption : 300W
Control and Programming	Control Channel: 14/25/32 control channel model, Control Mode: Standard DMX512, auto run, sound, DMX Signal Connection: 3 & 5 pin XLR input/output, Menu Display: 16 million pixels LCD display
Electronic Control Technology	Fixture reset is controlled through menu or light console 0-100% dimmer Constant current drive mode Temperature sensor, intelligently adjust light source power DMX channel level monitoring Fixture information query Intelligent fan speed adjustment Initial brightness setting for all colors Over current, over voltage and overheating protection Over current over voltage and overheating protection.
Physical	Flight case packaging 2 in 1: 40 x 29 x 21 CM, Gross weight: 33.4 KG, Net Weight: 7.6 KG, Product dimensions: 42 x 31 x 47 CM
IP Rating	IP20

Download Drivers

Wash 300 Controller Files

Share On

User Manual

Share On

Lamp Source	Average Life: 50000 hours, Beam angle: 8°- 54°, Lamp type: 19pc 15W RGBW 4in1 LED, Lens: High quality optical lens
Color System	RGBW 4 in 1
Effects	All-optical domain dimming High light output, low glare Fast Strobe: 1-25HZ Color macro and gradual color change eﬀects
Moving Parameter	Angle: Pan 540° Tilt 270° PAN and TILT adopt an electro-optic reset system which automatically resets the parameters if any change is caused by accident.
Power Supply	AC100-240V 50/60Hz Switch Power Consumption : 300W
Control and Programming	Control Channel: 14/25/32 control channel model, Control Mode: Standard DMX512, auto run, sound, DMX Signal Connection: 3 & 5 pin XLR input/output, Menu Display: 16 million pixels LCD display
Electronic Control Technology	Fixture reset is controlled through menu or light console 0-100% dimmer Constant current drive mode Temperature sensor, intelligently adjust light source power DMX channel level monitoring Fixture information query Intelligent fan speed adjustment Initial brightness setting for all colors Over current, over voltage and overheating protection Over current over voltage and overheating protection.
Physical	Flight case packaging 2 in 1: 40 x 29 x 21 CM, Gross weight: 33.4 KG, Net Weight: 7.6 KG, Product dimensions: 42 x 31 x 47 CM
IP Rating	IP20
